The picture shows the model CBZ200 popping boba machine, CBZ200 production line using PLC and servo control system, automatic processing design.
Parameters of the whole production line:
Model | CBZ200 |
Capacity (kg/h) | Up to 300 |
Depositing stroke (Pcs) | 15-25times |
Chilling Capacity | 8PH |
Length of the whole line (m) | 7-9m |
Electric power needed | 14-40kw |
Compressed air consumption Compressed air pressure | 1.5m3/min 0.4-0.6 Mpa |
Gross weight (Kgs) | Approx. 3000 |
Boba weight | According to boba diameter (Customized from 3-30mm or more) |
Machine size | 9250x1700x1780mm |
CBZ200 popping boba Production Line
The picture shows the model CBZ200 popping boba machine, CBZ200 production line using PLC and servo control system, automatic processing design. The popping boba production line adopts PLC/ servo process control and built-in touch screen (HMI), it is easy to operate. In addition, Due to the insulation design of depositing hopper and nozzle, the production line can simultaneously produce popping boba and agar boba.
The standard production capacity range of this line is 300kg/h. The main parts of the popping boba production line are made of stainless steel SUS304, also be customized SUS316. Popping boba production line is specially designed with continuous operation and material recovery device, so as to avoid waste. By adjusting the depositing machine to adapt to different sizes of popping bobas.
Kitchen system
1. 3-Layers fixed cooker with scrapper stirrer: 2sets
2. Lobe pump for transferring cooked syrup: 4sets
3. Cooling tank with scrapper stirrer: 2sets
4. Electrical control cabinet and skid frame: 1set
Combined with the production process, the popping boba produced by this production line is bright in color, round in shape, beautiful in appearance and delicious in taste. According to the production process, the production line contains three kinds of liquids, which are the jam material liquid (that is, the liquid inside the popping boba), the coagulation liquid (that is, the surface layer of the popping boba, the main component is sodium alginate), and the preservation liquid ( Mainly used to protect the popping boba)
